3-Stations ZN650 Plastic Thermoformer

ZN650 Plastic Thermoforming Machine has three stations (froming cutting and stacking) and suitable for the molding of HIPS, PS, PP, PVC, PET, etc. plastic sheets, processing high transparency, high stretch, shallow stretch, round, square, irregular, up and down bidirectional stretching, flanging and other products, producing various boxes, dishes, trays, bowls, covers, industrial packaging, food packaging, cosmetics packaging and other packaging and other plastic products.The machine interface adopts delta 10 inch color touch screen, professional operation interface, corresponding to common operation methord, solves the problem of upgrading control, powerful memory space, and sets interfaces including automatic operation, manual operation, function setting, mechanical animation, fault display, equipment document, safety guidance, etc. The whole system is safe and stable.

product details

Function Brief Introduction

The machine mainly consists of three working positions: forming, cutting and stacking. During operation, the plastic sheet is fed into the machine, where it is then heated and formed into the desired shape using both positive and negative pressure techniques. Afterward, the formed product is automatically cut to the accurate size and shape according to the pre-programmed die and the stacking station will automatically collect and and count the final products, and the scrap rewinder will roll the scrap sheet automatically.

Application

In terms of product applications, the Three-Position Fully Automatic Plastic Positive and Negative Pressure Thermoforming Machine can be widely used in various industries, such as packaging, food-processing, medical equipment, electric appliance, automotive parts, and more, providing a cost-effective and efficient solution for plastic product manufacturing.

Key features and benefits of this machine include

1. High efficiency: Thanks to its fully automatic design and optimized work processes, the machine is capable of producing a large number of plastic products in a short amount of time, greatly improving production efficiency.

2. Precision forming: The machine is equipped with advanced heating and forming systems, which can ensure the accurate and consistent shaping of the plastic sheet into the desired product.

3. Wide material compatibility: The machine can handle various types of plastic sheets, including PVC, PET, PS, PP, and more, making it versatile and suitable for different applications.

4. Easy operation and maintenance: The machine is designed with user-friendly interfaces and modular structures, which facilitate easy operation and maintenance.

Technical Parameters

Description	ZN-650
Suitable Products	Disposable Plastic lids/covers, clamshell boxes, plates, (egg) trays , containers, etc.
Suitable Material	PLA, PP, PS, PET, PVC, EPS,CORN STARCH etc
Max. Width of Material	690mm
Max. Forming Width	650mm
Max. Forming Length	500mm
Max. Forming Depth	100mm
Max. Cutting Speed	10-40 Cycles/min
Material Thickness	0.1mm-1.5mm
Heating Power	52KW
Total Power	75KW
Power	380V / 50HZ (220V 60HZ) Three phase four wire
Pressure of Water Supply	0.2MPa
Water Consumption	0.3m³/h 3P Chiller
Air Pressure	0.6-0.8MPa
Air Exhaust Volume	≥1.2m³/min
Air Compressor	11KW
Machine Install Size	9200×2100×2450mm
Machine Packing Size	9300×2200×2600mm
Weight	9000KG
